3 Wiring and Connection
3.4.4 Main Circuit Wires
3-24
For Three-phase, 400V
Combination of
SERVOPACK and
Converter
*1
Terminal
Symbols
Screw Size
for
Terminals
Tightening
Torque
(Nxm)
HIV Wire
Size in mm
2
(AWG)
Crimp Terminal
Model
(Made by J.S.T.
Mfg Co., Ltd.)
*2
SGDV-750J
SGDV-
COA3ZDA
SERVO-
PACK
P, N
M8
15.0
Bus bar
attached to the
converter
–
U, V, W
M8
3.0
22 (4)
R22-8
DU, DV,
DW
M6
3.0 3.5
(12)
3.5-6
M8
9.0 to 11.0
22 (4)
R22-8
Converter
P, N
M8
3.0
Bus bar
attached to the
converter
–
L1, L2, L3
M8
3.0
22 (4)
R22-8
1, 2
M8
3.0 22
(4)
R22-8
CN101
(24 V, 0 V)
–
(Connector)
–
1.25 (16)
–
B1, B2
M8
3.0
8 (8)
R8-8
M8
9.0 to 11.0
22 (4)
R22-8
SGDV-101J
SGDV-
COA5EDA
SERVO-
PACK
P, N
M8
15.0
Bus bar
attached to the
converter
–
U, V, W
M8
3.0
38 (1)
R38-8
DU, DV,
DW
M6
3.0 3.5
(12)
3.5-6
M8
9.0 to 11.0
38 (1)
R38-8
Converter
P, N
M10
12 to 20
Bus bar
attached to the
converter
–
L1, L2, L3
M10
12 to 20
38 (1)
R38-10
1, 2
M10
12 to 20
38 (1)
R38-10
CN101
(24 V, 0 V)
–
(Connector)
–
1.25 (16)
–
B1, B2
M10
12 to 20
8 (8)
R8-10
M8
9.0 to 11.0
38 (1)
R38-8
