Loading/saving settings
56
3.1 Loading settings
PSSnet SHL - Basic Configuration
Pilz GmbH & Co. KG, Felix- Wankel Str. 2, 73760 Ostfildern
3.1.3 Loading from a file
The device allows you to load the configuration data from a file in the con-
nected network if there is no AutoConfiguration Adapter connected to the
device.
Select the
Basics: Load/Save dialog.
In the "Load" frame, click
X
"from URL" if you want the device to load the configuration data
from a file and retain the locally saved configuration.
X
"from URL & save to Switch" if you want the device to load the
configuration data from a file and save this configuration locally.
X
"via PC" if you want the device to load the configuration data from
a file from the PC and retain the locally saved configuration.
In the "URL" frame, enter the path under which the device will find
the configuration file, if you want to load from the URL.
Click "Load configuration".
The URL identifies the path to the tftp server from which the device
loads the configuration file. The URL is in the format
tftp://IP address of the tftp server/path name/file name
(e.g. tftp://149.218.112.5/switch/config.dat).
Example of loading from a tftp server
Before downloading a file from the tftp server, you have to save the
configuration file in the corresponding path of the tftp servers with
the file name, e.g. switch/switch_01.cfg
(see on page
60
„Saving in a file on URL“)
In the "URL" line, enter the path of the tftp server, e.g. tftp://
149.218.112.214/switch/switch_01.cfg.
