Configuring the ports
PSSnet SHL - Basic Configuration
Pilz GmbH & Co. KG, Felix- Wankel Str. 2, 73760 Ostfildern
73
Select the
Basics:Power over Ethernet dialog.
With “Function on/off” you turn the PoE on or off.
With “Send Trap” you can get the device to send a trap in the follow-
ing cases:
– If a value exceeds/falls below the performance threshold.
– If the PoE supply voltage is switched on/off at at least one port.
Enter the power threshold in “Threshold”. When this value is exceed-
ed/not achieved, the device will send a trap, provided that “Send
trap” is enabled. For the power threshold you enter the power yield-
ed as a percentage of the nominal power.
“Nominal Power” displays the power that the device nominally pro-
vides for all PoE ports together.
“Reserved Power” displays the maximum power that the device pro-
vides to all the connected PoE devices together on the basis of their
classification.
“Delivered Power” shows how large the current power requirement
is at all PoE ports.
