10 Automation Cues

An Automation Cue is an action/demand that is sent from the DC-Post to any external device
connected to the DC-Post for the purpose of being inserted into a Show Playlist. Upon installation of
the DC-Post, Automation Cues can be predefined by the operator, transferred from an “xml” file, or
added manually. Automation Cues can be added to CPL's and SPL's using CineLister.

A Macro Automation Cue consists of two parts, an automation cue and a trigger cue. Trigger Cues are
explained fully in Section “Trigger Cues” below. A trigger cue is an action that is sent to the DC-Post,
whereas an automation cue is sent from the DC-Post. Also, Macro Cues are are a sequence of
actions, whereas an Automation Cue is only one action.

10.1 Macro Creation Using “Macro Editor”

•

Go to the CineLister Menu, click Doremi Labs and select “Macro Editor”.

•

The “Macro Editor” GUI will appear (see Figure 43).

•

Click on the “Plus” button to begin the creation process.

•

You will be prompted to enter a name for the Marco Automation (see Figure 44).

•

Click the “Ok” button when you are done and the “Macro Editor” GUI will appear.

•

Click on Save after you are done creating the Macro Automation Cue.

•

The new Macro will appear in the “Macro Editor” Window (see Figure 45).

•

Click the Save button when you are done. It is very important to click the save button whenever
you have finished completing any task.

Figure 43: “Macro Editor” Window

DPT.OM.001128.DRM Page 38 of 101 Version 1.2

Doremi Labs

“Insert a new

Action” Button

“Macro”

Window

“Plus”

Button

“Minus

Button
