Page 79
17.2 eCNA Device Removal
To remove the eCNA device, select it in the left pane of the Device Manager and click the “Delete”
button (see Figure 98).
17.3 JNior Device Addition
•
Click the Add button and select JNior from the “Device Manager” window (see Figure 99).
•
Enter the IP address of the JNior device in the “Server IP” field, the port number field should
already contain the appropriate value (factory default value). See Figure 99.
•
The JNior device documentation will provide you the correct Username and Password values
(the factory default values).
•
Click the Save button to save the settings, you will be asked for a password.
Figure 99: Device Manager GUI – JNior Device Set Up
17.4 JNior Device Removal
To remove the JNior device, click on it in the left part of the Device Manager GUI and click the “Delete”
button (see Figure 99).
DPT.OM.001128.DRM Page 79 of 101 Version 1.2
Doremi Labs
JNior IP
address field
“Add”
button
“Delete”
button
Default “Port”
number
