In the event that no
DVB-S2
signal is available, the information windows will show
“
UNLOCK
”.
MPEG4 DVB-S2
It works similarly to the MPEG-4 DVB-T section.
CAM (Conditional-access module) DVB-S2
It works similarly to the CAM DVB-T section.
3.3.3.2.2.5.4.- Constellation
This function represents the constellation of the
DVB-S2
signal. As well as this graphic
representation, the same screen shows the
Link Margin
and
MER
measures of the
DVB-S2
signal.
In the extended information windows, the network identifier is also shown (if available),
the number of supplier services and other different items of data on the tuned channel
in each of the two windows. On the first of the windows these data are:
SID
,
VPID
(for
audio channels, value 0 will be shown),
NID
and
APID
. At the bottom of the window,
audio and video information is shown: type of
MPEG
,
video resolution
, and
audio
channel
selected among all the available ones. On the second window, the respective
data are:
Profile
and
Level ID
, video format and audio mode. If the service is
MHP
, this
is also shown. At the bottom, more information is given on audio and video: frame
frequency and aspect ratio, audio bit rate and audio sampling frequency.
