Measures Config.
band is selected, the icon is a parabolic aerial. If the FM radio is selected, the symbol shown is
a musical note.
- Band change -
3.3.1.2.- LNB and Preamplifiers
This menu accesses the LNB, ExtraBurst and DiSEqC configurations.
3.3.1.2.1.- LNB (quick key
)
This accesses the menu for configuring the power supply to preampl. and LNB.
This option varies depending on whether the terrestrial or satellite band has been selected. In
the terrestrial band when this function has been selected a window will automatically open by
which the installer may select the voltage of the pre-amplifiers.
This window is shown below:
When the meter is on, the option that appears selected will
always be OFF.
A
short pressure on the key
, alternates between the terrestrial and satellite bands,
while a
long pressure on key
, enables commuting between the terrestrial, satellite
and FM radio bands.
