3.3.3.2.1.7.- Field strength
This unit corresponds to a measure of intensity of electric field in a given point. For the
accomplishment of this measure we should take into account all the elements, from the signal
collection system used (antenna) up to the measuring equipment (prior, cable ...).
For the H60, this unit is calculated for a Televes DAT-HD antenna and 10 meters of cable T100
(for more information, please visit http://www.televes.com).
- Field Strength -
ICT legislation establishes minimum standards that must be taken at the point of signal
collection. In the case of terrestrial television you can see the following table:
Signal Type
Frequencies (MHz)
Field Strength
Analog
470 - 582
65 dB(µV/m)
Analog
582 - 830
70 dB(µV/m)
Digital
470 - 862
56.4 - 61.7dB(µV/m)
3+20 log f (MHz) dB(µV/m)
