Measures Config.
Terrestrial band Satellite band
- Channel plans -
On selecting a satellite plan, a list will unfold allowing the selection of the desired band and
polarity (
VL
,
HL
,
VH
,
HH
and
ALL
). The option
ALL
includes all the channels of both bands, and
both polarizations, ordered by frequency.
3.3.1.3.3.- Audio Carrier
The options appearing in this function will depend on the color standard that has been selected:
To select a user-desired option, you may use the
.
As well as the sound carrier frequencies for each standard, the window offers two extra options:
Nicam
and
Other
.
PAL B/G
5.50 y 5.74
PAL D/K
6.50 y 6.74
PAL I
6.00
SECAM B/G
5.50 y 5.74
SECAM L
6.50 y 5.85
SECAM D/K
6.50 y 5.85
If LNB power is necessary, it is recommended to select the option
Auto
in the pre-amplifier and LNB power menu.
