36
Measures Config.
The frequencies corresponding to each of these channels are defined by the standard
50494:2006
When this mode is activated, an indicator appears in the upper right corner with the flashing
SCR indicator. In analyzer and combo mode, the traze colour of the spectrum becomes blue.
Both the channel mode as the frequency mode we can see the SCR CHANNEL that is currently
selected.
- The SCR mode indicator -
Channel SCR0 SCR1 SCR2 SCR3 SCR4 SCR5 SCR6 SCR7
Frequency (MHz) 1680 1420 2040 1210 1680 1420 2040 1210
