turboIP-G2 Performance Enhancement Proxy Revision 2
Introduction CD-TURBOIP-G2
1–14
1.5 Remote Control
The operator may monitor and control (M&C) the turboIP-G2 through the ‘CONSOLE’ M&C
serial port (RS-232 or RS-485 2- or 4-wire), or via 10/100/1000 BaseT Ethernet using the RJ-45
‘MGT’ port (available on units manufactured from November 2010 forward).
1.6 Summary of Specifications
Feature Specifications
Rear Connectors (5)
(as of November 2010)
• LAN, WAN, MGT (1 each): RJ-45 10/100/1000BaseT Ethernet, auto-sensing and
auto-crossover
• CONSOLE: EIA-232 DB-9F
• AC POWER: IEC-320
Front Panel Status
LEDs
• Link and activity for LAN, WAN
• Power indication with on/off control
Temperature
Operating:
Storage:
5° to 60° C (140° F)
0° to 75° C (167° F)
Humidity Operating: 5 to 90% @ 40° C (104° F), non-condensing
Vibration
Operating: 5 to 17 Hz, 0.1'' double amplitude displacement 17 to 500 Hz, 1.5G
acceleration peak-to-peak (max.)
Shock Operating: 15G acceleration peak (1 ms duration)
Safety EN-60950 (CE)
EMC FCC Part 15 Subpart B / EN55022-EN55024 (CE)
Chassis Half-Width
Dimensions:
Weight:
Power:
1.68H x 8.25W x 15.3D inches (43H x 210W x 389D mm)
<7 lbs (3.2 kg)
100 to 240V AC, 50 to 60 Hz, 90W max.
Chassis Full-Width
Dimensions:
Weight:
Power:
1.73H x 16.75W x 12.3D inches (44H x 425.4W x 312D mm)
8.5 lbs (3.86 kg)
90 to 264V AC, 47 to 63 Hz, 110W max.
Cooling Fans Two internal fans
