Command Guide of MGSW-28240F
Example:
To display the MAC-based VLAN information.
Switch # show vlan mac
MAC Address VID Interfaces
----------- --- ----------
00-40-55-00-00-00 1 GigabitEthernet 1/1
4.21.113 show vlan protocol
Command:
show vlan protocol [ eth2 { <etype> | arp | ip | ipx | at } ] [ snap { <oui> | rfc-1042 |
snap-8021h } <pid> ] [ llc <dsap> <ssap> ]
show Show running system information
vlan VLAN status
protocol Protocol-based VLAN status
eth2 Ethernet protocol based VLAN status
<etype> Ether Type(Range: 0x600 - 0xFFFF)
arp Ether Type is ARP
at Ether Type is AppleTalk
ip Ether Type is IP
ipx Ether Type is IPX
llc LLC-based VLAN status
<dsap> DSAP (Range: 0x00 - 0xFF)
<ssap> SSAP (Range: 0x00 - 0xFF)
snap SNAP-based VLAN status
<oui> SNAP OUI (Range 0x000000 - 0XFFFFFF)
rfc-1042 SNAP OUI is rfc-1042
snap-8021h SNAP OUI is 8021h
<pid> PID (Range: 0x0 - 0xFFFF)
Default:
N/A
Usage Guide:
To display the Protocol-based VLAN information.
Example:
To display the Protocol-based VLAN information.
-432-
