NV9000-SE Utilities • User’s Guide 9
2. Using the Interface
The SE Utilities Window
Common Commands
Throughout the work area certain common commands appear. These commands perform the same
action no matter where they appear. On multi-destination display areas, you can press ‘Esc’ on your
keyboard to cancel an action or press ‘Enter’ on your keyboard to accept a change.
Many tabbed windows have
Previous
,
Next
,
Finish
and
Cancel
buttons at the bottom of the screen.
These buttons become enabled or disabled (grey-out) on a moment-by-moment basis depending on
whether the current page and data entry require the button. Click a button to perform the related
function.
•
Previous
— Opens the previous page in the data entry cycle.
•
Next
— Continues to the next page in the sequence.
•
Finish
— Saves the current information and completes the procedure; clears all fields so that new
information can be entered immediately.
•
Save
— Saves the current information and completes the procedure.
•
Revert to Saved
— Ignores any current changes and restores data to the last time it was saved.
•
Cancel
— Clears the fields without saving any information.
•
X
— Closes the window or dialog box. If clicked before
Finish
or
Save
is clicked, the window
closes without saving any changes.
Tabs
Information is organized into tabbed windows. Clicking a tab brings the related window forward.
The tab that is currently forward is active. All other tabs in the background are inactive.
To close the currently active tab (and window), from the menu bar, select ‘Window > Close Active
Tab’. The active tab closes.
To close all inactive tabs, from the menu bar, select ‘Window > Close Inactive Tabs’. The inactive
tabbed windows close, but the active tab remains open.
Tables
Data entered in a page or wizard is saved in tables. Tables are accessed through the ‘Views’ pane.
Tables can be adjusted to make viewing information easier:
• Adjust the position and width of the table columns by sliding the column dividers between the
column headers.
• Sort the table based on the data in a specific column by clicking the column header. Clicking
once gives an ascending sort (Z to A); clicking again gives a descending sort (A to Z).
• Some dialog boxes or pages have check boxes. When a check box is checked, the correspond-
ing item is selected; if a check box is unchecked, the item is deselected.
Entering Data
Data is entered in fields. Fields can be “free text” in which you type in the data, or fields have drop-
down lists from which an entry is selected.
Menu Bar
The menu bar displays near the top of the window and is always present. The menu bar provides
access to menu options that perform system tasks. To open a menu, click on title on the menu bar. A
