Product overview
2.4.2 EP2028 ­ Technical data
Technical data EP2028­0001 EP2028­0002
Fieldbus EtherCAT
Fieldbus connection 2 x M8 socket (green)
Number of outputs 8
Output connections [ } 95] M8 M12
Load type ohmic, inductive, lamp load
Rated output voltage 24 V
DC
(­15%/+20%)
Output current max. 2.0 A each channel, total current of all outputs max. 4 A
Short circuit current max. 4.0 A
Module electronic supply derived from control voltage Us
Module electronic current
consumption typically 120 mA
Output driver supply derived from load voltage Up
Output driver current consumption typically 8 mA per channel
Power supply connection Feed: 1 x M8 plug, 4­pin
Onward connection: 1 x M8 socket, 4­pin
Process image 8 output bits
Electrical isolation Control voltage/fieldbus: yes
Permissible ambient temperature
during operation ­25°C ... +60°C
0°C ... +55°C (according to cULus, see UL Requirements)
0°C ... +55°C (according to ATEX, see special conditions [
} 92])
Permissible ambient temperature
during storage ­40°C ... +85°C
Vibration / shock resistance conforms to EN 60068­2­6 / EN 60068­2­27
EMC resistance/emission conforms to EN 61000­6­2 / EN 61000­6­4
Protection class IP65, IP66, IP67 (conforms to EN 60529)
Installation position variable
Approvals CE, cULus, ATEX
2.4.3 EP2028­000x ­ Process image
Channel 1 to Channel 8
You will find the 8 digital outputs from the module (here using the EP2028­0001 as an example) under
Channel 1 to Channel 8.
