Product overview
2.13.2
EP28160010 Technical Data
Technical data
EP28160010
Fieldbus
EtherCAT
Fieldbus connection
2 x M8 socket (green)
Number of outputs
16
Two 9 pin SUBD sockets
Load type
ohmic, inductive, lamp load
Rated output voltage
24 V
DC
(15%/+20%)
Output current
max. 0.5 A each channel, individually shortcircuit
proof, total current of all outputs max. 4 A
Short circuit current
Maximum 1.5 A
Module electronic supply
derived from control voltage Us
Module electronic current consumption
typically 120 mA
Output driver supply
derived from load voltage Up
Output driver current consumption
max. 30 mA for all channels
Power supply connection
Feed: 1 x M8 plug, 4pin
Onward connection: 1 x M8 socket, 4pin
Process image
16 output bits, 16 input bits (diagnostic)
Electrical isolation
Control voltage/fieldbus: yes
Permissible ambient temperature during operation
25°C ... +60°C
0°C ... +55°C (according to cULus, see UL
Requirements)
Permissible ambient temperature during storage
40°C ... +85°C
Vibration / shock resistance
conforms to EN 6006826 / EN 60068227
EMC resistance/emission
conforms to EN 6100062 / EN 6100064
Protection class
IP65, IP66, IP67 (conforms to EN 60529)
Installation position
variable
Approvals
CE, cULus
2.13.3
EP28160010 Status LEDs
Fig. 44: EP28160010 Status LEDs
