Mounting and cabling
Fig. 88: BG20000000, mounting the protection enclosure
3.5.3
ATEX Documentation
Note
Notes about operation of EtherCAT Box Modules (EPxxxxxxxx) in potentially
explosive areas (ATEX)
Pay also attention to the continuative documentationNotes about operation of EtherCAT
Box Modules (EPxxxxxxxx) in potentially explosive areas (ATEX) that is available in the
download area of the Beckhoff homepage http:\\www.beckhoff.com!
3.6
Signal connection
3.6.1
Digital outputs M8 and M12
The digital output modules connect the binary control signals from the automation unit on to the actuators at
the process level.
The signals are connected via screwin M8 connectors (EP2xxx0001) or screwin M12 connectors
(EP2xxx0002).
EP2xxx
95
Version 2.1.0
