3 Wiring and Connection
3.5.1 Linear Scale Signal (CN2) Names and Functions
3-42
3.5
Linear Scale Connections
This section describes connection examples between linear scale and SERVOPACK,
and the terminal layout of the connector CN2 for connecting a linear scale.
3.5.1 Linear Scale Signal (CN2) Names and Functions
The following table shows the names and functions of the linear scale signals (CN2).
∗ The pins 3 and 4 are connected to the internal circuit. Do not use them.
Signal Name
Pin Number
Function
PG 5 V
1
Linear scale power supply +5 V
PG 0 V
2
Linear scale power supply 0 V
–
3
*
–
–
4
*
–
PS
5
Serial data (+)
/PS
6
Serial data (
−)
Shield
Shell
–
