RIGOL Chapter 6 MATH and Measurements
6-8 MSO2000A/DS2000A User’s Guide
Press MATH  Operate to select “Logic”:
 Press Formula to select the desired logic formula and the default is “AND”.
 Press Source A and Source B to select the desired channels (CH1, CH2 or any
channel of D0-D15).
 Press and use to adjust the vertical position of the operation results.
 Press and use to adjust the vertical scale of the operation results.
 Press Invert to turn the inverted display of the operation results on or off.
 Press Threshold A and use
to set the threshold of source A in logic
operation.
 Press Threshold B and use to set the threshold of source B in logic
operation.
Note: When Source A or Source B is set to any channel of D0-D15,
Threshold A or Threshold B will be hidden automatically and cannot be set.
 Press Label to define a label for the operation results. For the details, please
refer to “ MATH Label”.
 HORIZONTAL POSITION and HORIZONTAL SCALE can also be
used to adjust the horizontal position and scale of the operation results.
