Network Settings
User Guide 63
DHCP/BOOTP
Specifies whether or not to automatically obtain an IP address using DHCP or
BOOTP.
Auto-IP
When the Auto-IP is set to On, the IP address from 169.254.0.1 through
169.254.255.254 will usually be generated by itself. But if the IP address using
DHCP server or Manual settings has been decided and becomes a candidate as
the result of configuration, the Auto-IP address isn’t generated and decided even
when the Auto-IP is set to On.
If the IP address has already been entered in IP Address using Manual settings,
delete the address.
To enable the settings, restart network. Automatically-generated IP address
appears on Confuguration page under Device Information on navigation menu.
IP Address
If DHCP/BOOTP is set to Off, then a static IPv4 address can be entered in this field
as part of the system network settings. When DHCP/BOOTP is set to On, a
dynamic IPv4 address is assigned to the device, and the field is grayed out. The for-
mat of the IPv4 address is a sequence of numbers separated by dots.
For example: 192.168.110.171
Subnet Mask
Specifies the subnet mask. When DHCP/BOOTP is turned On, a dynamic IPv4
address is assigned to the device, and the field is grayed out.
Domain Name
Specifies the domain name of the domain to which the printing system belongs. It
should not contain the host printer name, for example, "abcde.com". abcde.com.
When DHCP/BOOTP is turned On, a dynamic IPv4 address is assigned to the
device, and the field is grayed out.
3.
Click Submit button.
IPv4 settings (Common)
1.
Click TCP/IP under Network Settings on the navigation menu. The TCP/IP Settings
page opens.
2.
This section includes the following items for configuration.
Default Gateway
Specifies the IP address of the default gateway. When DHCP/BOOTP is turned On,
a dynamic IPv4 address is assigned to the device, and the field is grayed out.
DNS Server (Primary, Secondary)
Specifies the IP addresses of the primary and secondary DNS (Domain Name Sys-
tem) servers. When DHCP/BOOTP is turned On and Use DNS Server from DHCP
is selected, you can select to use the DNS server obtained via DHCP. When DHCP/
BOOTP is turned On and Use following DNS Server is selected, you can enter
static DNS server information in the Primary and Secondary fields provided.
