Table 182. Port detailed statistics information (Continued)
Description
Field
A count of MAC control frames received on this interface with an opcode
indicating the PAUSE operation. This counter does not increment when the
interface is operating in half-duplex mode.
802.3x Pause Frames
Received
The number of frames discarded from this port due to being an unacceptable
frame type.
Unacceptable Frame Type
The total number of octets of data (including those in bad packets) transmitted
on the network (excluding framing bits but including FCS octets). This object
can be used as a reasonable estimate of Ethernet utilization. If greater precision
is desired, the etherStatsPkts and etherStatsOctets objects must be sampled
before and after a common interval.
Total Packets Transmitted
(Octets)
The total number of packets (including bad packets) received that were 64
octets in length (excluding framing bits but including FCS octets).
Packets Transmitted 64
Octets
The total number of packets (including bad packets) received that were
between 65 and 127 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted 65-127
Octets
The total number of packets (including bad packets) received that were
between 128 and 255 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted 128-255
Octets
The total number of packets (including bad packets) received that were
between 256 and 511 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted 256-511
Octets
The total number of packets (including bad packets) received that were
between 512 and 1023 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted
512-1023 Octets
The total number of packets (including bad packets) received that were
between 1024 and 1518 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted
1024-1518 Octets
The total number of packets transmitted that were longer than 1518 octets
(excluding framing bits, but including FCS octets) and were otherwise well
formed. This counter has a max increment rate of 815 counts per sec at 10
Mb/s.
Packets Transmitted > 1518
Octets
The maximum Ethernet frame size that the interface supports or is configured
to use, including the Ethernet header, CRC, and payload. The minimum size
is 1500; The maximum size is 12270; The default size is 9198.
Maximum Frame Size
The number of frames that were transmitted to the port’s segment.
Total Packets Transmitted
The total number of packets that higher-level protocols requested be
transmitted to a subnetwork-unicast address, including those that were
discarded or not sent.
Unicast Packets Transmitted
The total number of packets that higher-level protocols requested be
transmitted to a multicast address, including those that were discarded or not
sent.
Multicast Packets
Transmitted
