MSD-54 Series Users Guide (Command Guide)
81
3.3.11 Serial port
@SCT Set COM port communication
Command
format @SCT, port, setting
Return value
format @SCT, port, setting
Parameter port : COM port
0 = All ports, 1 = RS-232C CH1 port, 2 = RS-232C CH2 port
setting : Communication settings
• Baud rate (4800, 9600, 19200, 38400 [bps] [Default]: 9600[bps]
• Data length (8, 7[bit] [Default]: 8[bit])
• Parity (NONE, EVEN, ODD [Default]: NONE)
• Stop bit (1, 2[bit] [Default]: 1[bit])
For set values, see Table 3.3.11a.
Example Send
Receive
@SCT,1,24
@SCT,1,24
Set RS-232C CH1 port as follows:
Baud rate=19200[bps], Data length=8[bit],
Parity=None, Stop bit=1[bit]
Terminated normally.
Related info. 8.10.1 Communication setting
Note After IP address or serial communication setting is changed, communication may
be disabled. Change the environmental settings of communication based on the
MSD settings after changed.
@GCT Get COM port communication
Command
format @GCT
Return value
format @GCT, rs_232c_1, rs_232c_2
Parameter rs_232c_1 : Communication settings of RS-232C CH1 port
rs_232c_2 : Communication settings of RS-232C CH2 port
• Baud rate (4800, 9600, 19200, 38400[bps] [Default]: 9600[bps]
• Data length (8, 7[bit] [Default]: 8[bit])
• Parity (NONE, EVEN, ODD [Default]: NONE)
• Stop bit (1, 2[bit] [Default]: 1[bit])
For set values, see Table 3.3.11a.
Example Send
Receive
@GCT
@GCT,24,24
Get communication settings of the COM ports.
RS-232C CH1 port and CH2 port are set as following;
Baud rate:19200[bps], Data length: 8[bit], Parity:
None, Stop bit: 1[bit].
Related info. 8.10.1 Communication setting
