DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 109
Chapter 9 - Clip management
9.2 Playback
9.2.1 Playback monitor
To playback a clip or playlist you must first load it. Double-tap a thumbnail to load the clip or
playlist you wish to view. The selected clip is loaded into the playback monitor and paused.
The first frame is shown.
9.2.2 Transport buttons
The buttons at the bottom of the screen are used as follows:
The audio channels recorded with the clip are played back in the monitor speaker or in the
headphones connected to the rear jack if this is set up in the audio menu.
playback
indicator
audio bars
clip name
menu button
clip time
properties
transport
buttons
back button
playback
timecode media
indicator
Button Use
Returns to the thumbnail overview
Opens the menu.
Plays back the clip in reverse. Tapping again increases reverse playback
speed to the following rates: -1x, -2x, -4x, -8x, -16x, -32x and -64x.
Tap to freeze the clip; tap again to continue playback of the clip.
Fast forward. Tapping again increases playback speed to the following
rates: 1x, 2x, 4x, 8x, 16x, 32x and 64x.
back
menu
