DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 12 - Side panel menu
ch3 AGC profile
Standard, Quiet, Noisy
Selects the AGC (Automatic Gain Control)
profile.
1
Prod
channel 4
ch4 lvl control
AGC standard, AGC-12dB,
Front, Level1,
Lev1+Front, Level2,
Lev2+Front, Fixed
Selects a recording level control.
1
Prod
ch4 fixed lvl
0..99 (50)
Sets the fixed recording level (when fixed
control is selected).
1
Prod
ch4 filter
None, 150Hz
Selects the channel filter.
1
Prod
ch4 AGC profile
Standard, Quiet, Noisy
Selects the AGC (Automatic Gain Control)
profile.
1
Prod
source ch1
Rear1, Rear2,
Wrx1,[Wrx2], Front1,
[Front2], MicRear, AES1,
AES2, SDI In1..8,
Sidetone, Program, Eng,
Prod, Mute
Selects a recording source for channel 1.
1
Prod
source ch2
Rear1, Rear2,
Wrx1,[Wrx2], Front1,
[Front2], MicRear, AES1,
AES2, SDI In1..8,
Sidetone, Program, Eng,
Prod, Mute
Selects a recording source for channel 2.
1
Prod
source ch3
Rear1, Rear2,
Wrx1,[Wrx2], Front1,
[Front2], MicRear, AES1,
AES2, SDI In1..8,
Sidetone, Program, Eng,
Prod, Mute
Selects a recording source for channel 3.
1
Prod
source ch4
Rear1, Rear2,
Wrx1,[Wrx2], Front1,
[Front2], MicRear, AES1,
AES2, SDI In1..8,
Sidetone, Program, Eng,
Prod, Mute
Selects a recording source for channel 4.
1
Prod
monitoring
hdph mode left
Channel, Source
Selects channel/source mode for the
headphones left channel input.
0
Prod
hdph source left
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Sidetone,
Program, Eng, Prod,
Mixer
Selects a source to be routed to the
headphones left channel when input mode is
source.
0
Prod
hdph channel left
Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4
Selects a channel or channel mix to be routed
to the headphones left channel when input
mode is channel.
0
Prod
speaker mode
Hdph L+R, Hdph L,
Hdph R
Selects channel/source mode for the speaker
input.
0
Oper
hdph mode right
Channel, Source
Selects channel/source mode for the
headphones right channel input.
0
Prod
Menu item
Values
Description
Level File
