Page 46: Overview
46
DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 3 - General set-up
Enabling or disabling indicators
The indicators on the viewfinder on-screen display can be enabled or disabled in the
VF
>
INDICATORS
submenu of the viewfinder menu.
3.7 Side panel home screen
3.7.1 Overview
The home screen of the side panel display provides information on audio, video and recording
parameters as well as information on media and power.
Power/media indicator
This indicator can be set to display information about the current media or
about the camcorder’s power system. Select the indicator in the
VF
>
INDICATOR
>
SELECTABLE
menu.
Storage:
Displays the remaining recording time (in minutes) on the current media.
When the selected media is not available the indication “No info” will be
shown.
Batt:
Displays the supplied voltage of the battery or the external power supply.
Timecode
This indicator displays the timecode.
Indicator
Function
Compression
indicator
Power
information
Timecode or
userbits
Media
information
Compression
information
Video mode
information
Warning icon
Media
indicator
Audio
bars
Basic audio
settings
Basic system
settings
Basic video
settings
Timecode
indicator
DEFAULT
