DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 147
Chapter 13 - Viewfinder menu
Level 0..99 (SD:70, HD:30) Sets the upper limit level of detail
enhancement for soft detail. Note: default
values for SD and HD are different. 2 Scene
Black lvl 2
Dyn. black On, Off Turns dynamic black on or off 2 Scene
Auto black On, Off Turns automatic black on or off 3 Scene
Master black 0..99 (50) Sets black level adjustment (master) 2 Scene
Black lvl R 0..99 (50) Sets black level adjustment (R) 3 Scene
Black lvl G 0..99 (50) Sets black level adjustment (G) 3 Scene
Black lvl B 0..99 (50) Sets black level adjustment (B) 3 Scene
Black stretch 3
Black stretch O > Off Turns black stretch on or off. Use to enhance
image details in the dark parts of the image. 3 Scene
Level 0..99 (50) Sets black stretch level when black stretch is
on. ‘50’ is no stretch, values above 50 are
black press. 3 Scene
Contrast Stretch, Press Sets contrast to black stretch or black press
when black stretch is on. 3 Scene
Knee 2
Knee Auto, Var, Off Sets knee mode:
Auto = automatic;
Var = variable (manual);
Off = no knee function. 2 Scene
Knee type Y, NAM Selects knee type:
Y = luminance;
NAM = luminance of highest RGB
component. 3 Scene
Point 0..99 (0) Sets the point where the knee gamma curve
begins (in manual mode). 3 Scene
Slope 0..99 (10) Sets the slope of the knee gamma curve (in
manual mode). 3 Scene
Limit 0..99 (0) Sets the knee limitation level. S1 Scene
Desat On, Off Turns knee desaturation on or off. S1 Scene
Desat lvl 0..99 (50) Sets the desaturation level when knee mode
is variable and desaturation is on. S1 Scene
Auto point 0..99 (30) Sets the knee point when knee mode is set to
automatic. S1 Scene
Auto ref 0..99 (30) Sets the auto reference level when knee
mode is set to automatic. S1 Scene
Auto limit 0..99 (50) Sets the auto limitation level when knee mode
is set to automatic. S1 Scene
Skin 2
Skin Off, 1, 2, 1+2 Turns skin detail off or on and selects the
memory position. 2 Scene
State Off, On Shows the current skin state. 2
View Off, On Turns indication of the selected area on or off. 2
Menu item Values Description Level File
