84
DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 6 - Audio setup
6.2.6 Gain settings
Set the input gain level in the AUDIO
>
INPUTS
menu for:
•
the front microphone inputs,
•
the rear microphone inputs,
•
the rear line-level inputs, and
•
the optional wireless audio input.
6.3 Recording audio
6.3.1 Select source
To select the source for each of the four recording channels:
1.
Go to the AUDIO
>
CHANNELS
menu.
2.
Tap one of the SOURCE
CH
buttons numbered 1 to 4.
3.
Tap the arrows in the pop-up box to select a source for that channel.
The possible sources are:
•
Rear1 - analog audio 1 input,
•
Rear2 - analog audio 2 input,
•
Wrx1 and Wrx2 - wireless audio channels (optional),
•
Front1 - front microphone or stereo front microphone channel 1 (optional),
•
Front2 - stereo front microphone channel 2 (optional)
•
MicRear - rear mini-jack headset microphone,
•
AES1 - digital audio input channel 1 via BNC connector,
•
AES2 - digital audio input channel 2 via BNC connector,
•
SDI In1..8 - embedded digital audio input channels from the SDI input,
•
Sidetone - sidetone (intercom loopback) channel (when in systemized operation),
•
Program - intercom Program channel (when in systemized operation),
•
Eng - intercom Engineering channel (when in systemized operation),
•
Prod - intercom Production channel (when in systemized operation), or
•
Mute.
Four channels are always recorded. When a recording channel is not used, set the recording
source for that channel to Mute.
