DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 115
Chapter 11 - Specifications
Chapter 11
Specifications
11.1 Specifications for DMC 1000
Item Value
General
Dimensions (H x W x L) 240 x 150 x 330 mm (9.4 x 5.9 x 13.0 in) without lens, VF and battery
Weight (approx.) 5.0 kg (11.0 lbs) without VF; 5.7 kg (12.6 lbs) including VF
Operating temperatures 0 to +40 °C (32 to +104 °F)
Storage temperatures -20 to +60 °C (-4 to +140 °F)
Humidity 10% to 90% (relative humidity)
Power requirements 15 VDC (11.0 to 17.0 VDC)
Power consumption (standby) 45 W (with active imaging, VF, compression, buffer and lens)
Power consumption (recording) 49 W (while recording to REV)
Camera section
Lens mount 2/3-inch television lens mount, bayonet type
Optical system F1.4 prism system
Optical filters Clear, 1/4 ND, 1/16 ND, 1/64 ND (motorized)
color correction filters 3200 K, 4700 K, 5600 K, 7500 K, two AWB presets and continuous auto
white balance; variable from 2200 K to 20000 K in 10 K steps
Pick-up device Three 2/3-inch full HD Xensium™ CMOS imagers
Digital signal processing 22-bit accuracy
Exposure Electronic exposure down to 1/2000 s
Clean scanning 50 Hz scanning: 51.0 to 103.0 Hz; 60 Hz scanning: 61.0 to 151.0 Hz
Video standard 576i/480i mode 1080i/720p mode
Temporal frequencies 50/59.94 Hz 50/59.94 Hz
S/N Ratio (Y-signal) 61 dB (typical) 54 dB (typical)
Modulation depth (Y-signal) 70% at 5 MHz (16:9) 50% at 27 MHz (800 TV-lines)
Aspect ratio 16:9, 4:3 and letterbox 16:9
Sensitivity 2000 lux (186 ft cd) at F8 typical
