DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 12 - Side panel menu
remote tally
On, Off
Turns remote tally signalling by the OCP 400
on or off.
3
ip address
x.x.x.x (192.168.1.10)
Sets the camcorder’s IP address in the C2IP
network.
3
subnetmask
x.x.x.x (255.255.255.0)
Sets the camcorder’s subnet mask in the C2IP
network.
3
gateway
x.x.x.x (0.0.0.0)
Sets the camcorder’s gateway address in the
C2IP network.
3
timing
ver.timing
1..625
Set the vertical timing
3
-
H-phase coarse
0..863
3
-
H-phase fine
0..99
3
-
CVBS subc.phase
0..99
3
-
date/time
time
HH
0..23 (12)
Sets real time clock (hours).
2
-
MM
0..59 (00)
Sets real time clock (minutes).
2
-
SS
0..59 (00)
Sets real time clock (seconds).
2
-
date
MM
1..12 (1)
Sets month.
2
-
DD
1..31 (1)
Sets day of the month.
2
-
YY
0..98 (8)
Sets year (last two digits).
2
-
time zone
UTC-12:00 .. UTC+12:00
(UTC+00:00)
Selects the time zone in 0:30 hrs steps.
2
-
sidepanel
backlight
1..15 (15)
Sets the brightness level of the backlight of
the side panel display.
0
-
calibration
execute
Runs the touch screen calibration procedure.
S1
-
titlebar
timecode, userbits
Shows timecode or userbits on the sidepanel
title bar.
1
-
home screen
default, day, night
Selects a home screen style for the side panel
display:
default = extended information panel;
day = white style (better visibility);
night = dark style.
0
-
VF-menu on SPD
On, Off
Turns on the superimposed viewfinder menu
on the side panel display. Note: use the Cam/
Menu button to switch to Cam View to see
the viewfinder menu.
0
-
VF-menu on CVBS
On, Off
Turns on the superimposed viewfinder menu
on the CVBS output signal. Note: make sure
the analog output port is set to CVBS.
0
-
files
Menu item
Values
Description
