138 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 12 - Side panel menu
12.4 System menu
Menu item Values Description Level File
hardware
viewfinder
VF monitoring Y, R, G, B, x-G Selects type of signal to view in viewfinder:
Y = luminance signal;
R,G,B = red, green or blue channel;
x-G = inverted green channel 1 Oper
detail
detail On, Off Turns detail for viewfinder signal on or off. 1 Oper
detail lvl 0..99 (50) Sets detail level for viewfinder signal. 0 Oper
lens
autoiris
autoiris On, Off Turns auto iris on or off. 1 Oper
peak average 0..99 (78) Sets the balance between peak and average
video level. 0 = strong reaction to highlights,
99 = less reaction to highlights. 3 Oper
setpoint 0..99 (20) Sets auto iris exposure level. 3 Oper
autoiris const. 3
iris gain 5..10 (5) Sets auto iris response speed: Lower values
give slower speeds. 3 Oper
iris threshold 0..99 (63) Sets the threshold value for the auto iris
function 3 Oper
mom. iris setpoint 0..99 (8) Sets momentary iris setpoint level. 1 Oper
RE iris comp. On, Off Turns the iris compensation on or off. Use this
setting to compensate for iris loss when a
range extender is used. 1 -
extended iris
gain speed 1..5 (5) Sets the gain speed for extended auto iris. 3 Oper
iris min. F5.6, F8.0, F11.0, F16.0 Sets the minimum iris value for extended auto
iris. 3 Oper
gain max. 0..15dB (15dB) Sets the maximum gain value for extended
auto iris. 3 Oper
iris max. F1.4, F2.0, F2.8, F4.0,
F5.6 Sets the maximum iris value for extended
auto iris. 3 Oper
lens type Std, WA Selects the lens type (used to apply the
correct shading type):
Std = standard lens;
WA = wide angle lens. 1 Lens
buttons
contrast button BlkStrKnee, Knee, BlkStr
Disabled Assigns a function to the contrast button:
BlkStrKnee = black stretch + knee
Knee = knee
BlkStr = black stretch
Disabled = nu function 0 Oper
user buttons
