DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 127
Chapter 12 - Side panel menu
hdph source right Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Sidetone,
Program, Eng, Prod,
Mixer Selects a source to be routed to the
headphones right channel when input mode is
source. 0 Prod
hdph channel right Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4 Selects a channel or channel mix to be routed
to the headphones right channel when input
mode is channel. 0 Prod
speaker mute On, Off Mutes speaker signal (turns audio off). 0 Oper
outputs
rear
rear Enabled, Disabled Enables or disables the rear1 and rear2
outputs. Disable the outputs to save power. 1 Prod
rear 1 mode Channel, Source Selects channel/source mode for the rear1
output. 1 Prod
rear 1 source Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer Selects a source to be routed to the rear1
output when input mode is source. 1 Prod
rear 1 channel Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4 Selects a channel or channel mix to be routed
to the rear1 output when input mode is
channel. 1 Prod
rear 2 mode Channel, Source Selects channel/source mode for the rear2
output. 1 Prod
rear 2 source Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer Selects a source to be routed to the rear2
output when input mode is source. 1 Prod
rear 2 channel Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4 Selects a channel or channel mix to be routed
to the rear2 output when input mode is
channel. 1 Prod
AES Audio
AES mode Channel, Source Selects input mode for the AES audio output. 1 Prod
AES 1 source Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer Selects a source to be routed to the AES1
output when input mode is source. 1 Prod
AES 1 channel Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4 Selects a channel or channel mix to be routed
to the AES2 output when input mode is
channel. 1 Prod
Menu item Values Description Level File
