DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 12 - Side panel menu
AES 2 source
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer
Selects a source to be routed to the AES2
output when input mode is source.
1
Prod
AES 2 channel
Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4
Selects a channel or channel mix to be routed
to the AES2 output when input mode is
channel.
1
Prod
SDI out
SDI channel 1
Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4, Rear1, Rear2,
Wrx1, [Wrx2], Front1,
[Front2], MicRear, AES1,
AES2, SDI In1..8, Eng-
Ret, Prod-Ret, Sidetone,
Program, Eng, Prod,
Mixer
Selects a channel, source or intercom channel
to embed in the SDI audio output channel.
1
Prod
SDI channel 2
same as above (ch2)
same as above
1
Prod
SDI channel 3
same as above (ch3)
same as above
1
Prod
SDI channel 4
same as above (ch4)
same as above
1
Prod
SDI channel 5
same as above (ch1)
same as above
1
Prod
SDI channel 6
same as above (ch1)
same as above
1
Prod
SDI channel 7
same as above (ch1)
same as above
1
Prod
SDI channel 8
same as above (ch1)
same as above
1
Prod
inputs
front
gain
-20..+25 (0)
Sets input gain in dB for front mic input (mono
or stereo).
1
Prod
limiter
On, Off
Turns audio limiter for Front mic input on or
off.
1
Prod
rear1
gain (mic)
-5..+30 (0)
Sets input gain (in 5 dB steps) for rear 1 mic
input.
1
Prod
gain (line)
0..+20 (0)
Sets input gain (in 5 dB steps) for rear 1 line
input.
1
Prod
rear 1 limiter
On, Off
Turns audio limiter for rear 1 input on or off.
1
Prod
rear2
gain (mic)
-5..+30 (0)
Sets input gain (in 5 dB steps) for rear 2 mic
input.
1
Prod
gain (line)
0..+20 (0)
Sets input gain (in 5 dB steps) for rear 2 line
input.
1
Prod
rear 2 limiter
On, Off
Turns audio limiter for rear 2 input on or off.
1
Prod
wireless 1
gain
0..20 (0)
Sets input gain (in 5 dB steps) for wireless
microphone input 1.
1
Prod
Menu item
Values
Description
Level File
