DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 129
Chapter 12 - Side panel menu
wireless 2
gain 0..20 (0) Sets input gain (in 5 dB steps) for wireless
microphone input 2. 1 Prod
setup
test tone Disable, -6dBFS,
Headroom Selects 1KHz test tone level (only audible
when color bar is on):
Disabled = no test tone
-6dBFS = test tone level is at -6dBFS
Headroom = test tone level is the same as the
selected audio headroom. 3 Prod
headroom -18dBFS, -20dBFS Selects audio headroom. 3 Prod
stereo option Mono, Stereo Set to Stereo when the optional DMC 1180
stereo microphone connector kit is installed. S1 -
mixer
source 1 Ch1, Ch2, Ch3, Ch4,
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer, Mute Selects a source for audio mixer source 1. 1 Prod
source 2 Ch1, Ch2, Ch3, Ch4,
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer, Mute Selects a source for audio mixer source 2. 1 Prod
source 3 Ch1, Ch2, Ch3, Ch4,
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer, Mute Selects a source for audio mixer source 3. 1 Prod
source 4 Ch1, Ch2, Ch3, Ch4,
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer, Mute Selects a source for audio mixer source 4. 1 Prod
level 1 0..99 (50) Sets mix level for source 1. 1 Prod
level 2 0..99 (50) Sets mix level for source 2. 1 Prod
level 3 0..99 (50) Sets mix level for source 3. 1 Prod
level 4 0..99 (50) Sets mix level for source 4. 1 Prod
intercom
prod Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8 (SDI In 3) Selects which input is used for the intercom
Production (Prod) channel. 1 Prod
Menu item Values Description Level File
