DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 12 - Side panel menu
exposure
exposure
Nom, Var, 50Hz, 60Hz,
1/200, 1/500, 1/1000,
1/2000
Selects exposure time. This function is also
controlled by the exposure time switch at the
front of the camcorder.
1
-
lighting
-10 . . . +10 (0)
Sets the exposure correction (in steps of 1 Hz)
to synchronise with lighting frequency when
exposure mode is 50 Hz or 60 Hz.
1
-
var. exp. time
50 Hz .. 3270 Hz,
(50.0 Hz), 60 Hz ..
3280 Hz (60.0 Hz)
Sets the exposure time in 0.5 Hz steps when
exposure mode is Var (you can also use the
exposure button at the front of the camcorder)
1
Scene
flare
flare
On, Off
Turns the lens flare compensation on or off.
3
Lens
flare RGB
R
0..99 (10)
Sets the lens flare compensation level (R)
3
Lens
G
0..99 (15)
Sets the lens flare compensation level (G)
3
Lens
B
0..99 (25)
Sets the lens flare compensation level (B)
3
Lens
knee
knee
Off, Auto, Var
Sets knee mode:
Off = no knee function.
Auto = automatic;
Var = variable;
1
Scene
knee source
Y, NAM
Selects knee type:
Y =Y-component/luminance;
NAM = Non-Additive Mix (luminance of
highest RGB component)
3
Scene
desaturation
On, Off
Turns knee desaturation on or off.
3
Scene
white limiter
On, Off
Turns white limiter on or off. Use this function
to limit highlight levels in the video signal.
3
Scene
slope/point
slope
0..99 (0)
Sets the slope of the knee gamma curve (in
manual mode).
3
Scene
point
0..99 (10)
Sets the point where the knee gamma curve
begins (in manual mode).
3
Scene
desaturation lvl
0..99 (50)
Sets the desaturation level when knee mode
is variable and desaturation is on.
3
Scene
white imiter lvl
0..99 (54)
Sets the white limiter level. This is the
luminance level at which limiting occurs.
3
Scene
gamma
gamma mode
1, 2, LIN, VAR
Selects gamma mode:
1= Nominal curve (76,76,76);
2 = Low curve (50,50,50);
LIN = Linear curve (0,0,0);
VAR = Variable curve (76,76,76)
3
Scene
gamma curve
ARD, CCIR, 6xARD, RAI,
Cinestyle1, Cinestyle2,
CineLog, BBC04,
BBC05,BBC06
Selects a standard curve for gamma
correction.
3
Scene
Menu item
Values
Description
Level File
