DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 121
Chapter 11 - Specifications
11.4.3 1080P JPEG 2000 profiles
☞
Note
☞
Note
The following profiles are only available when the optional DMC 1130 1080P license is
installed.
11.4.4 MPEG-2 I-frame
☞
Note
☞
Note
The following profiles are only available when the optional DMC 1120 MPEG-2 board is
installed.
resolution GoP
struct.
GoP
length GoP
seq. frame
rate chroma
sampling bit-
depth
CBE/
VBE profile/
level
bitrate
(Mbps)
23.98 psF (segmented frame wrapped)
1920x1080p I-frame 1 I 23.98 4:2:2 10 bits VBE n/a 50
1920x1080p I-frame 1 I 23.98 4:2:2 10 bits VBE n/a 75
1920x1080p I-frame 1 I 23.98 4:2:2 10 bits VBE n/a 100
25 psF (segmented frame wrapped)
1920x1080p I-frame 1 I 25 4:2:2 10 bits VBE n/a 50
1920x1080p I-frame 1 I 25 4:2:2 10 bits VBE n/a 75
1920x1080p I-frame 1 I 25 4:2:2 10 bits VBE n/a 100
29.97 psF (segmented frame wrapped)
1920x1080p I-frame 1 I 29.97 4:2:2 10 bits VBE n/a 50
1920x1080p I-frame 1 I 29.97 4:2:2 10 bits VBE n/a 75
1920x1080p I-frame 1 I 29.97 4:2:2 10 bits VBE n/a 100
resolution GoP
struct.
GoP
length GoP
seq. frame
rates chroma
sampling bit-
depth
CBE/
VBE profile/
level
bitrate
(Mbps)
720P 1280x720p I-frame 1 I 25 4:2:0 8 bits VBE MP@HL 60
1280x720p I-frame 1 I 25 4:2:0 8 bits VBE MP@HL 80
1280x720p I-frame 1 I 29.97 4:2:0 8 bits VBE MP@HL 60
1280x720p I-frame 1 I 29.97 4:2:0 8 bits VBE MP@HL 80
1080i 1440x1080i I-frame 1 I 25 4:2:0 8 bits VBE MP@H-14L 60
1440x1080i I-frame 1 I 29.97 4:2:0 8 bits VBE MP@H-14L 60
1920x1080i I-frame 1 I 25 4:2:0 8 bits VBE MP@HL 80
1920x1080i I-frame 1 I 29.97 4:2:0 8 bits VBE MP@HL 80
625i 720x576i I-frame 1 I 25 4:2:2 8 bits VBE 422@ML 30
720x576i I-frame 1 I 25 4:2:2 8 bits VBE 422@ML 40
720x576i I-frame 1 I 25 4:2:2 8 bits VBE 422@ML 50
