144 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 13 - Viewfinder menu
Focus/Wrx Focus, Wrx, Off Selects information that is shown by the
focus/wireless indicator:
Focus = lens focus distance (0 = close-up, 99
= infinity)
Wrx = wireless microphone receiver status;
Off = indicator is not shown. 0 Oper
Iris On, Off Turns the iris indicator in the viewfinder on or
off. This indicator shows the F-stop value
(F1.4 .. F22) of the iris opening of the lens. 0 Oper
Filter On, Off Turns the optical filter indicator on or off. This
indicator shows the selected neutral density
optical filter. 0 Oper
Audio bars On, Off Turns the audio bars on or off. These four bars
at the right side of the image indicate audio
levels for channel 1 to 4.. 0 Oper
Time Code On, Off Turns time code indicator on or off. 0 Oper
Selectable Storage, Batt, Off Selects information that is shown by the
bottom left indicator:
Batt = power information;
Storage = storage time in minutes left on
selected media (when media is not available
“No info” is shown).
Off = indicator is not shown. 0 Oper
Markers 0
Marker On, Off Turns the cadre marker on or off. 0 Oper
Type 15:9, 14:9, 4:3 Sets the aspect ratio of the cadre marker. 0 Prod
Style Dot, Shad, Both Sets the style of the cadre marker:
Dot = dotted lines;
Shad = shaded areas;
Both = dotted lines and shaded areas. 0 Oper
Shading Shading, Black Sets shading style for the cadre marker (when
cadre marker style is set to Shad or Both):
Shading = transparent area;
Black = black area. 0 Oper
Centre Cross On, Off Turns the centre marker on or off. 0 Oper
Safe area 0
Safe Area On, Off Turns the safe area marker on or off. This
marks the screen area that represents 80% of
the whole viewfinder picture. 0 Oper
Type 16:9, 15:9, 14:9, 4:3 Selects the aspect ratio of the safe area
marker. 0 Prod
OSD 0
white lvl 0..99 (70) Sets the white (positive) level of the
characters: 0 = low intensity; 99 = high
intensity. 0 Oper
Black lvl 0..99 (30) Sets the black (shading) level of the
characters: 0 = black; 99 = no shading. 0 Oper
Mode On > Time Selects the menu display to be permanently
on or to disappear after set time. 0 Oper
Menu item Values Description Level File
