48 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 3 - General set-up
Basic system settings Displays clip name, time and date and
package version information. not shown
Basic video settings Displays important video settings:
video gain, color temperature, optical
filter, knee, black stretch, exposure
time, auto iris indicator and range
extender indicator. not shown
Basic audio settings Displays audio sources and recording
level controls for channel 1 to 4. not shown
Audio bars These bars display the audio levels for channels 1 to 4.
Video mode information Displays current video standard and recording source.
Media information
(primary media) Displays the selected recording media
(REV, CF1, CF2 or EXT) and remaining
recording time in minutes on the
media.
When the selected media is not
available a dash (“-”) will be shown. Displays the selected recording media
(REV, CF1, CF2 or EXT) and remaining
recording time on the media.
F = full media, B = blank media
Media information
(preferred media) not shown Displays the selected preferred media
(REV, CF1, CF2 or EXT) and remaining
recording time on the media.
F = full media, B = blank media
Media indicator Indicates the selected recording
media (REV, CF1, CF2 or EXT). not shown
Message area not shown Displays camcorder messages,
warnings and information.
Indicator/information Default home screen Night or day home screen
