Chapter 5 - Video setup
All display messages, menus and markers, and the viewfinder signal processing (zebra, focus
assist, VF detail) are applied to the output signal. Crispening of the viewfinder signal is not
applied.
If the Option switch on the viewfinder is set to the On position, only selected markers are
shown. VF detail is still applied.
5.1.2 Analog connectors
Analog video
The Analog Out connector provides a 1.0 Vpp CVBS analogue output signal. This signal is only
present if the connector is terminated correctly with 75
Ω. A linear time code signal according
to SMPTE 12M-1999 can also be provided for locking external units to the time code generator
of the camcorder.
The Analog In connector accepts a 1.0 Vpp CVBS external video signal for genlocking the
camcorder and for recording. This signal can also be viewed in the viewfinder. A black burst
signal can be used for genlocking.
A linear time code signal according to SMPTE 12M-1999 can also be supplied to this connector
for locking the time code generator of the camcorder to an external unit.
Digital audio
The Analog Out connector can also be set in the SYSTEM > HARDWARE > PORTS menu to
provide an AES digital audio output signal. Select the audio source for the output in the
AUDIO
> OUTPUTS > AES AUDIO menu.
The Analog In connector can also be set in the SYSTEM > HARDWARE > PORTS menu to accept
an AES digital audio input signal. Select AES audio as a recording source in the
AUDIO
> OUTPUTS > AES AUDIO menu.
