DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 139
Chapter 12 - Side panel menu
user 1 Start play, Stop play,
Pause play, Rewind,
Forward, , Record, Ext
iris, Call, Eng Talk,
Prod Talk, Disabled Assigns a function to user button 1. 1 Oper
user 2 Start play, Stop play,
Pause play, Rewind,
Forward, , Record, Ext
iris, Call, Eng Talk,
Prod Talk, Disabled Assigns a function to user button 2. 1 Oper
lens
RET button Ext signal, Playback Assigns a function to the RET button on the
lens. 0 Oper
handgrip 0
zoom control Enabled, Disabled Enables or disables the zoom control on top of
the camcorder’s carrying handle. 0 Oper
record switch Enabled, Disabled Enables or disables the record switch under
the carrying handle. 0 Oper
ports
digital out Normal, VF Selects the output signal for the digital output.
When VF is selected the output signal marker
(‘VF’) is shown on the text overlay. 1 -
analog in CVBS, Timecode,
AES Audio, Audiosync Selects the signal for the analog BNC input
connector. 1 -
analog out CVBS, Timecode,
AES Audio, Audiosync Selects the signal for the analog BNC output
connector. 1 -
IEEE 1394 Off, Exclusive, Both Selects IEEE 1394 interface operation mode:
Exclusive = playback via IEEE 1394 only;
Off = no playback via IEEE 1394;
Both = normal playback and simultaneous
playback via IEEE 1394. 1 -
genlock
lock source None, Analog, Digital Selects the type of source to which the
camcorder locks. 1 -
fan control 3
silent mode Rec, Off Selects mode for cooling fan:
Rec = switches temporarily to silent fan
profile during recording
Off = always use selected fan profile 3 Prod
profile Normal, Silent, Cool Selects a profile for the cooling fan:
Cool = maximum cooling (fast response)
Normal = normal cooling (linear)
Silent = minimal cooling (slow response) 3 Prod
network 3
camera # 0..99 (17) Sets the logical camera number within the
C2IP network. 3
remote rec On, Off Turns remote recording by the OCP 400 on or
off. 3
Menu item Values Description Level File
