DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 131
Chapter 12 - Side panel menu
12.2 Video menu
Menu item Values Description Level File
levels
gain
gain VAR, [preset -], 0dB,
[preset +], [preset ++],
[preset +++] Selects variable gain or gain preset (see
presets below for values) 1 -
var. gain - 6.0dB .. 42.0dB (0dB) Sets variable gain (in 0.1dB steps). 1 -
gain presets
- -6dB, -3dB Selects gain value for - preset. 3 -
+ +3dB, +6dB, +9dB,
+12dB, +15dB, +18dB Selects gain value for + preset. 3 -
++ +6dB, +9dB, +12dB,
+15dB, +18dB, +24dB Selects gain value for ++ preset. 3 -
+++ +9dB, +12dB, +15dB,
+18dB, +24dB, +30dB,
+36dB, +42dB Selects gain value for +++ preset. 3 -
painting range +3dB, +6dB Selects painting range. 3 -
gain RGB
R 0..99 (50) Sets gain level (R) 3 Scene
G 0..99 (50) Sets gain level (G) 3 Scene
B 0..99 (50) Sets gain level (B) 3 Scene
black
black RGBM
R 0..99 (50) Sets black level adjustment (R) 3 Scene
G 0..99 (50) Sets black level adjustment (G) 3 Scene
B 0..99 (50) Sets black level adjustment (B) 3 Scene
M 0..99 (50) Sets black level adjustment (Master) 1 Scene
dynamic black On, Off Turns dynamic black on or off 1 -
auto black On, Off Returns black levels their default values
(50;50;50;50) 1 -
black stretch
black stretch On, Off Turns black stretch on or off. Use to enhance
image details in the dark parts of the image. 3 Scene
black contrast Stretch, Press Sets contrast to black stretch or black press
when black stretch is on. 3 Scene
black str. lvl 0..99 (50) Sets black stretch level when black stretch is
on. 50 is no stretch, >50 is black press. 3 Scene
filter wheels
N/D filter Clear, ND1/4, ND1/16,
ND1/64
Selects optical neutral density (ND) filter. This
function is also controlled by the filter wheel
button. Clear means that to filter is used. 0 -
Home filterwheel On, Off Runs the filterwheel home positioning. Allow
a few seconds for the filterwheel to adjust. 0 -
