DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
157
Chapter 13 - Viewfinder menu
Embedded chan 8
Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4, Rear1, Rear2,
Wrx1, [Wrx2], Front1,
[Front2], MicRear, AES1,
AES2, SDI In1..8, Eng-
Ret, Prod-Ret, Sidetone,
Program, Eng, Prod,
Mixer
Selects a channel or source to embed in the
SDI audio output channel.
1
Prod
Monitoring
1
Mode left
Channel, Source
Selects headphones left muff input mode.
1
Oper
Hdph left src
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Sidetone,
Program, Eng, Prod,
Mixer
Selects a source to be routed to the
headphones left channel when input mode is
source.
1
Oper
Hdph left chan
Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4
Selects a channel or channel mix to be routed
to the headphones left channel when input
mode is channel.
1
Oper
Mode right
Channel, Source
Selects headphones right muff input mode.
1
Oper
Hdph right src
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Sidetone,
Program, Eng, Prod,
Mixer
Selects a source to be routed to the
headphones right channel when input mode is
source.
1
Oper
Hdph right chan
Ch1, Ch2, Ch3, Ch4,
Ch1+2, Ch1+3, Ch2+4,
Ch3+4
Selects a channel or channel mix to be routed
to the headphones right channel when input
mode is channel.
1
Oper
Speaker mode
Source, Channel, Hdph L,
Hdph R, Hdph L+R
Selects speaker input mode.
1
Oper
Speaker mute
On, Off
Mutes speaker signal (audio off).
1
Oper
Setup
test tone
Disable, -6dBFS,
Headroom
Selects 1 kHz test tone level when color bar is
on:
Disable = no test tone
-6 dBFS = test tone level is at -6 dBFS
Headroom = level is the same as the selected
audio headroom.
1
Oper
headroom
-18dBFS, -20dBFS
Selects audio headroom.
1
Prod
front mode
Mono, Stereo
Set to stereo when the optional stereo front
microphone kit is installed.
S1
mixer
source 1
Ch1, Ch2, Ch3, Ch4,
Rear1, Rear2, Wrx1,
[Wrx2], Front1, [Front2],
MicRear, AES1, AES2,
SDI In1..8, Eng-Ret, Prod-
Ret, Sidetone, Program,
Eng, Prod, Mixer, Mute
Selects a source for audio mixer source 1.
1
Prod
Menu item
Values
Description
Level File
