Section 3
Front Panel Operation
3.22
SRQ
IFC
REN
ATN
EOI
LOCATION
MESSAGE
Press
[VIEW]
00000
'-'
2D
¼
to view the record memory
Press
[
↑] and [↓]
00001
'0'
30
¼
to scroll through the record memory
3.7.12 Using Keypress Macros
The following example uses the [SAVE] key to save and recall a
keypress macro to perform the previous sequence of operations. Use
the same setup configuration as the last example.
SRQ
IFC
REN
ATN
EOI
LOCATION
MESSAGE
LISTEN
LED on
BUS NUL 00
Press [SAVE][7]
Save Macro?
to start saving macro 7
Saving to Macro
7
After each key is pressed,
Key 001 in Macro
7
a message is displayed
Press
[STEP][ATN]
BUS
ACG00 00
¼
STEP
and ATN LED on
Press
[REN][TALK]
BUS ACG00 00
¼
¼
TALK
and REN LED on
to make the Analyzer488 the active controller
Press
[IFC]
BUS IFC 00
¼
¼¼
to clear the DMM bus interface
The IFC LED and front panel digit will flash
