Complete the following procedure at the telephone site location. Print the form in Table 3 below.
Table 3. Auto-Discovery Procedure
Step Explanation of Step Actions Installer Actions
1 Connect the phone line to the Type A telephone at its site
location. Wait 30 seconds. Connect Tip/Ring.
Wait 30 sec.
2 The following steps use “local” access programming (keypad required). Refer to GAI-
Tronics Pub. 42004-438 (available on
www.gai-tronics.com ) for further instructions.
 Type A telephones that do not include an integral keypad will require the use of a No.
51035-011 Keypad and No. 61504-048 Keypad Cable Assembly. The keypad and cable
must be connected to J13 on the PCBA.
 The CALL push-button connector J1 is exclusively used for local programming. Type A
telephones that include only the EMERGENCY push button must temporarily have the
associated switch harness plug moved from the EMERGENCY connector J7 to the CALL
push-button connector J1 on the PCBA.
3 Press the
CALL
or
EMERGENCY
push button (whichever is
connected to J1).
When the dial tone is heard from the speaker,
simultaneously press the “1” and “#” keypad buttons.
 If the telephone is in its factory-programmed Standard
Mode, the telephone generates a splash tone
(low to high sequence), followed by a success tone
(short beep).
 If the telephone has previously been used with TMA, it
generates only a success tone (short beep).
Press J1 button, then 1 + #
[ tone(s) ]
4 Immediately after the success tone, use the keypad and
press
*** to enter Programming Mode.
* * * [no tone]
5 Wait 2 seconds. Wait 2 sec.
6 Using the telephone’s keypad enter **0000 to gain access
with the factory-default password.
* * 0 0 0 0 [no tone]
7 Next, enter *127 followed by the phone number of the
telephone. When finished, press #. The telephone outputs
a success tone (from the speaker of hands-free phones, or
the earpiece at handset phones) to acknowledge the entry.
*1 2 7
_ _ _ _ _ _
#
[ one tone]
8 After the success tone, enter *123 followed by the
telephone number assigned to the TMA DTMF
Transceiver. When finished, press #. The phone outputs a
success tone to acknowledge the entry. *1 2 3
_ _ _ _ _ _
#
[ one tone]
9 After the confirmation tone, enter *99 to end the set up.
The telephone outputs a success tone to confirm
completion of the entry. *9 9
[ one tone]
