Table 12. Fields and Check Boxes for Input Switches
Field/Check Box Description
Priority
This field specifies the priority of the input. The following priorities are generally
assigned:
Priority 1 (highest) – Emergency calls
Priority 2 – (reserved for custom applications)
Priority 3 – Normal voice calls
Priority 4 – Calls that record or play a voice annunciation message
Priority 5 (lowest) – A switch used to start a call-in to TMA.
Disable Wake
Check this box to prevent the input from initiating a call.
Allow Disconn.
Check this box to permit an input having equal priority to terminate the call (after
expiration of the Emergency Disconnect Lockout time).
Emerg.
When checked, the call is designated as an “emergency” call and the telephone
activates the strobe output and enables the Disconnect Lockout Interval.
Autodial Row
This field directs the phone to a specific memory bank of auto-dial numbers, as
follows:
Enter 0 for Memory Bank 1 (Emergency)
Enter 1 for Memory Bank 2 (Assistance/Call)
Enter 2 for Memory Bank 3
Enter 3 for Memory Bank 4
Enter 4 for Memory Bank 5 (for the call-in autodial numbers)
Speed Dial with
Hook Sw.
When checked, a user must first remove the handset from the cradle, and then
depress a speed dial button.
Table 13. Output Devices
Designation Function
Out 1
Output contact 1 at TB2, in the telephone.
Out 4
Output contact 4 at TB5, in the telephone.
CR_LED
Controls the Call Received LED connected to pins 1 and 2 at J16 in the telephone.
CP_LED
Controls the Call Placed LED connected to pins 1 and 2 at J2 in the telephone.
Ringer
Controls the piezo ringer connected to pins 3 and 4 at J16 in the telephone.
Ser. Bus (J10:P4)
Controls pin 4 at J10 in the phone. This output is not available for any other
function if an optional Voice Annunciation Module is installed in the telephone.
