Pub. 42004-479B
Telephone Management Application (TMA) User Guide Page 36 of 128
e:\standard ioms - current release\42004 instr. manuals\42004-479b.doc
03/14
Parameter Common Name Function
HNDST
HOOKSW
(Fault Indicator 7) The HNDST HOOKSW fault input reports status of a switch connected to pins 3
and 4 at J8 (Key switch “C”) or other “named” sensory devices at the telephone.
The following selections are available in the “Common Name” field:
Not Used – when selected, a fault detected at the input is not reported.
Power Supply – is used if the input is connected to an external power supply fault
contact.
Door – enables reporting of an open door via a door switch sensor, if installed at a
weatherproof telephone or a stanchion with door access.
Tilt – enables reporting of a tilted (or leaning) condition of a telephone or
stanchion, if a tilt switch sensor is installed.
Strob Const Lamp (Strobe Constant-On Lamp) – is used if the input is
connected to a strobe status contact to indicate failure of the constant-on lamp.
Solar Panel Wiring – is used if the input is connected to a solar panel wiring fault
contact.
Stanchion Battery – is used if the input is connected to a stanchion battery fault
contact.
Key C – when selected, this input is listed by the generic “Key C” label
representing key switch contact “C.”
Hookswitch – indicates that this input is being used with a handset cradle
hookswitch. A fail status indicates that the handset has not been returned to the
cradle after use. (i.e. left free hanging)
PW ENABLE P2-3
(Fault Indicator 8) The PW JUMPER P2-3 input reports status of a switch connected to pins 2 and 3 at
J9 (Password Enable jumper) or other “named” sensory devices at the telephone.
The following selections are available in the “Common Name” field:
Not Used – when selected, a fault detected at the input is not reported.
Power Supply – is used if the input is connected to an external power supply fault
contact.
Door – enables reporting of an open door via a door switch sensor, if installed at a
weatherproof phone or a stanchion with door access.
Tilt – enables reporting of a tilted (or leaning) condition of a phone or stanchion, if
a tilt switch sensor is installed.
Strob Const Lamp (Strobe Constant-On Lamp) – is used if the input is
connected to a strobe status contact to indicate failure of the constant-on lamp.
Solar Panel Wiring – is used if the input is connected to a solar panel wiring fault
contact.
Stanchion Battery – is used if the input is connected to a stanchion battery fault
contact.
PW Jumper – when selected, this input is listed by the generic “Password
Jumper” label. This is appropriate for most uses with the jumper clip on header J9.
Fault Indicator 9
(Line Interrupt)
In the event telephone line service is disrupted for 8 or more minutes, the telephone
logs the event and performs a call-in to TMA only if the adjacent “Call-In After
Use” check box is checked. This selection cannot be changed.
