GAI-Tronics TMA Version 7.5.0 Telephone Management Application (TMA) User Guide (Ver. 7.5.0 and newer) - Manual (Page 27)

Pub. 42004-479B
Telephone Management Application (TMA) User Guide Page 24 of 128
e:\standard ioms - current release\42004 instr. manuals\42004-479b.doc
03/14
Click on the Phone Management Form to open. It is shown below.
The Phone Management Form consists of four areas: Phone Properties, Phone Data, Command Area, and
Synchronization.
Phone Properties Area
The Phone Properties area displays the phone properties in a tree structure. Each property contains
multiple parameters and can be expanded or collapsed by clicking or respectively.
To select all parameters of a property, click the property check box. To select an individual parameter,
click the parameter check box. All selected parameters will be processed based on user actions in the
Command area.
N OTE : The “Type A Advanced Settings” appears in the Phone Properties area only if this phone record is
Type A.
Phone Data
The Phone Data area contains parameters with value fields that correspond to the parameter and value
columns in the synchronization list. As each parameter is selected in the Phone Properties Tree, the
appropriate form is displayed in the Phone Data area for entering information in the value fields.
+ ־
Phone Data Area
Value Field
Phone Properties Configuration Forms
Phone Properties Area
Command Area
Synchronization Area
