105
Kaleido-X
User’s Manual
8 Repeat this procedure until you have added all required SSM/SFM transport streams to
your system configuration.
9 On the File menu, click Save. Alternatively, click the Save button on the toolbar.
Changes to the system are saved.
Adding unicast transport streams
To add a unicast transport stream
1 In the main window, click the System tab, and then click Description/Calibrations on
the second level tab bar.
2 Expand the System hierarchical list, and then click the appropriate network adapter
element, for the stream you wish to add:
• NETWORK ADAPTER 2 for a high-bitrate stream;
• alternatively, NETWORK ADAPTER 3, 4, 5, or 6, for a high-bitrate stream, in the case
of a four-port or six-port Kaleido-IP model;
• optionally, NETWORK ADAPTER 1 for a low-bitrate stream.
The supported stream types (Multicast, Unicast, HTTP, RTSP) are listed in the Tools
pane.
3 Drag Unicast from the Tools pane onto the network adapter element.
Note: Under the network adapter elements, transport streams are listed in
alphabetical order.
Transport stream
Program 1
Elementary streams (audio)
Elementary stream (video)
Group address
Protocol
Port number (or range)
Program 2
Elementary stream (video)
Elementary streams (audio)
Source IP address
