Built-in Communications Protocols
The multiviewer itself can be controlled by external devices (e.g. Kaleido-RCP2, router
control panels) or applications (e.g. router control software application, Remote Control
Gateway) via built-in communications protocols. Such devices or applications can be used
to command monitor wall operations (e.g. source assignment) or routing operations.
A router control device or application can control a Kaleido-X (7RU) or Kaleido-X16
multiviewer’s internal router module, or any multiviewer’s logical sources and monitor wall
destinations, via the KX Router logical router. It can also control other logical routers
configured within your multiviewer system. In the case of the KX Router logical router, the
device or application must support the NVISION Ethernet protocol - Compact router protocol.
The supported communications protocols are listed in the following table, with an
indication of the supported connection types (TCP/IP or serial), and the dedicated port
number on the multiviewer, in the case of a TCP/IP protocol.
Quintech
XRM/SRM/MRF/MRM Series
Protocol (serial)
No
SRM 2150 Matrix Switching
Systems
Snell (Pro-Bel)
General Switcher Protocol
(SW-P-02)
No
General Remote Protocol
(SW-P-08)
Yes
Halo, Aurora and Sirius
Controller (serial control)
Sony
Sony HKSPC (GVGNP
Emulator)
No
Sony routers (requires HKSPC
card); GVG routers (Ethernet)
Utah Scientific
PL-160/PL-320
No
AVS-1B
RCP-1
No
SC-1, SC-2, SC-3 series
RCP-3
Yes
SC-4 series (Ethernet only)
1.Deprecated. To be used with legacy configurations only.
2.To be used in most cases. Supports native locks, and aliases from router (provided system controller
has NV9000 router control system version 6.0.6 or later)
3.To be used in very specific scenarios involving physical router interconnects with tie lines, or with hybrid
router configurations. Contact Technical Support for more information (see
4.Our current implementations of the protocols listed above for Grass Valley (Thomson/Philips)
routers and controllers support neither the CM-4400 nor the CM-4000 system controllers.
5.For Thomson / Grass Valley Series 7000 devices, our current implementation of the Series 7000
Native Protocol supports serial devices, in addition to some Encore system controller models, which
are also supported over Ethernet. For other Series 7000 devices you wish to control via Ethernet, use
Sony HKSPC (GVGNP Emulator).
6.In the case of the Kaleido-X, and Kaleido-X16 multiviewers, the ES-Switch protocol is only supported
with a baud rate of 19200.
Company
Protocol
TCP/IP (port) Serial
Grass Valley (Miranda)
Kaleido Remote Control Protocol
Yes (13000)
Yes
Grass Valley
(Miranda/NVISION)
NVISION Ethernet protocol - Compact router Yes (5194)
No
Company
Protocol
Text
database
download Routers/Controllers
