289
Kaleido-X
User’s Manual
5 Select the Display alarm latch check box to enable the latched status indicators.
Configuring a UMD’s Source Reporting Behavior
To help you distinguish which sources are currently active on the monitor wall, monitors
that are capable of displaying an alarm status (e.g., video monitors,
subtitling monitors,
UMDs, alarm monitors) can have their borders, background or text configured to appear in
a specific color, based on their current source. UMDs can provide this information through
their text and background colors. See also:
Configuring a UMD’s Alarm Reporting Behavior ,
on page 287.
To configure a UMD’s background or text colors for source reporting
1 In XEdit, open a layout and click the UMD whose source reporting behavior you wish to
configure.
2 In the Properties pane, scroll down to the Alarms/Tallies section.
3 Click the text or background color box for a state you want associated with a distinctive
color, based on the monitor’s current source.
4 Click the button that appeared at the end of the box.
Critical and major The status indicator will blink when the current status is
critical or major.
Critical, major and
minor The status indicator will blink when the current status is
critical, major or minor.
Note: Double-click the UMD, if it is part of a composite monitor.
Blink mode Description
