2 In the Properties pane, set the transparency attribute to the appropriate value for your
purposes, by clicking the V-chip transparency box, and then using the slider or typing
the desired value directly into the box.
3 If you wish to preview the logo associated with a specific V-chip rating, select it from
the V-chip rating preview list. For example:
4 Make the appropriate assignments (see Assigning Logical Sources or Monitor Wall
Destinations to Monitors on page 250), and select the desired video level if necessary.
5 On the File menu, click Save.
Note: As its name implies, the V-chip rating preview is only a preview, and
its value is not saved with the layout.
Notes
• Unlike alarms, the V-chip rating associated with a video signal that is
currently monitored on the monitor wall is not relayed to the XEdit user
interface, when working in online mode.
• The V-chip monitor uses the holding time configured with the XDS
filtering calibrations for the associated video source (see Calibrating
Metadata Holding Time on page 150). Once the specified holding time has
expired, the V-chip monitor displays the N/A logo ( ).
• When V-chip data cannot be extracted from the current video signal, the
V-chip monitor displays the N/A logo ( ).
