153
Kaleido-X
User’s Manual
Calibrating DTMF Tone Sequences
The Kaleido-IP can detect 16 specific DTMF sequences in a SCTE 35 stream, to trigger up
to 8 DTMF break alarms and to return their status to normal. Define the sequences,
matching those used in the actual programs you wish to monitor.
To calibrate out-of-network, and in-network DTMF tone sequences
1 In the main window, click the System tab, and then click the Calibrations (Kaleido-IP)
tab on the second-level tab bar.
2 In the Tools pane, select the SCTE 35 profile you wish to configure, and then click DTMF
break 1 sequences.
CC holding time Set the delay (between 5 and 360 seconds, default value is
16 seconds) after which closed captions (608) are cleared:
DTVCC holding time Set the delay (between 15 and 360 seconds, default value
is 30 seconds) after which closed captions (708) are
cleared:
